Flags and Memory Selects
switch designators through which the pins are connected to the peripher-
als, and default switch settings.
To use the flags or memory selects on the expansion II interface, disable
any signal driving a flag or memory pin with the associated switch. The
pinout of the expansion connectors can be found in
EZ-Board Schematic" on page
Table 2-3. Flags and Memory Select Connections
Flag/Memory Pin
MS0
MS1
/
FLAG1 IRQ1
/ /
FLAG2 IRQ2 MS2
/
FLAG3 MS3
WDTRSTO_Z
2-6
B-1.
Peripheral
SDRAM
Parallel flash memory
Push buttons
Push buttons
SRAM
Reset Supervisory IC
ADSP-21479 EZ-Board Evaluation System Manual
"ADSP-21479
Peripheral Net Connected via
Switch
SDRAM_CS SW13.1
FLASH_CS SW13.2
PB1 SW13.3
PB2 SW13.4
SRAM_CS SW13.5
WDTRSTO SW13.6
Switch
Setting
(Default)
ON
ON
ON
ON
ON
OFF
