CyberData 011395 Operation Manual page 81

Web Page Item
2.3.13.1 Example Packets for Events
The server and port are used to point to the listening server and the 'Remote Event Server URL' is
the destination URL (typically the script running on the remote server that's used to parse and
process the POST events).
Note
Here are example packets for every event:
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 197
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>POWERON</event>
</cyberdata>
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 199
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>HEARTBEAT</event>
</cyberdata>
POST xmlparse_engine HTTP/1.1
Host: 10.0.3.79
User-Agent: CyberData/1.0.0
Content-Length: 196
Content-Type: application/x-www-form-urlencoded
<?xml version="1.0" encoding="ISO-8859-1"?>
<cyberdata NAME='CyberData Device' MAC='0020f70015b6'>
<event>BUTTON</event>
</cyberdata>
Operations Guide
Table 2-19. Events Configuration Parameters(continued)
Description
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the web
page items. First click on the Toggle Help button, and you will see a question mark
( ) appear next to some of the web page items. Move the mouse pointer to hover
over a question mark to see a short description of a specific web page item.
The XML is URL-encoded before transmission so the following examples are not completely
accurate.
931251H
Installing the InformaCast Enabled Speaker
Device Configuration
CyberData Corporation
74
