Web Page Item
Backup SIP Server 2
Backup SIP User ID 2
Backup SIP Auth ID 2
Backup SIP Auth Password 2
Remote SIP Port
Local SIP Port
Outbound Proxy
Outbound Proxy Port
Monitor User ID
Monitor Authenticate ID
Monitor Authenticate Password
Disable rport Discovery
Buffer SIP Calls
Re-registration Interval (in seconds)
Unregister on Boot
Keep Alive Period
Operations Guide
Table 2-13. SIP Page Parameters (continued)
Description
Enter a second backup SIP server address as an IPv4 address in dotted decimal
notation or a fully qualified domain name. This parameter also becomes the host
portion of the SIP-URI for the device's extension on the second backup SIP server.
This field can accept entries of up to 255 characters in length.
Specify the SIP User ID for the second backup SIP Server. This parameter becomes
the user portion of the SIP-URI for the device's extension on the second backup SIP
server. Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the second backup SIP server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the second backup SIP server. This parameter
is required for SIP registration authentication. Enter up to 64 alphanumeric characters.
The Remote SIP Port is the port number the device will use as the destination port
when sending SIP messages. The default Remote SIP Port is 5060. The supported
range is 0-65536. Enter up to 5 digits.
The Local SIP Port is the port number the device will use to receive SIP messages.
The default Local SIP Port is 5060. The supported range is 0-65536. Enter up to 5
digits.
Enter the Outbound Proxy address as an IPv4 address in dotted decimal notation or a
fully qualified domain name (FQDN). When an IP address is configured, the device
will send all SIP messages to this IP address. When an FQDN is configured, the
device will run DNS NAPTR, SRV, and A queries on the FQDN to resolve an IP
address to which it will send all SIP messages. This field can accept entries of up to
255 characters in length.
The Outbound Proxy Port is port number used as the destination port when sending
SIP messages to the outbound proxy. A value of 0 will default to 5060. The supported
range is 0-65536. Enter up to 5 digits.
Not applicable. This setting is only available with the Talk-Back Speaker.
Not applicable. This setting is only available with the Talk-Back Speaker.
Not applicable. This setting is only available with the Talk-Back Speaker.
Disabling rport Discovery will prevent the device from including the public WAN IP
address and port number in the contact information that is sent to the remote SIP
servers. This will generally only need to be enabled when using an SBC or SIP ALG in
conjunction with a remote SIP server.
Also referred to as delayed paging. Device will buffer up to 4 minutes of audio then
play back the recording after hang up.
The SIP Re-registration interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
When enabled, the device will send one registration with an expiry of 0 on boot.
The minimum time in milliseconds between keep-alive packets sent for nat traversal. A
value of 0 will disable keep alive packets.
