2. On the Multicast page, enter values for the parameters indicated in
Note
Web Page Item
Enable Multicast Operation
Blink Strobe on Multicast
Priority
Address
Port
Name
Buffer
Beep
Relay
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-15. Multicast Page Parameters
Description
Enables or disables multicast operation.
When selected, the Strobe will blink a scene when a multicast is received.
Note: The strobe settings will only appear if you are using the Strobe Kit. If
you are not using the Strobe Kit, you will not see the strobe settings.
Indicates the priority for the multicast group. Priority 9 is the highest (emergency
streams). 0 is the lowest (background music). SIP calls are considered priority 4.5.
See Section 2.3.9.1, "Assigning Priority"
Enter the multicast IP Address for this multicast group (15 character limit).
Enter the port number for this multicast group (5 character limit [range can be from
2000 to 65535]).
Note: The multicast ports have to be even values. The webpage will enforce this
restriction.
Assign a descriptive name for this multicast group (25 character limit).
Device will buffer up to four minutes of audio and then play back the recording after
the multicast stream finishes or after the buffer is full.
When selected, the device will play a beep before multicast audio is sent.
When selected, the device will activate a relay before multicast audio is sent.
Select desired scene (only one may be chosen).
Note: The strobe settings will only appear if you are using the Strobe Kit. If
you are not using the Strobe Kit, you will not see the strobe settings.
Strobe will blink ON at the specified brightness for 150ms then OFF for 350ms
during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0
over the course of about 3.5 seconds during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0
over the course of about 1.5 seconds during the duration of the event.
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second
during the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink on a multicast page. This is the maximum
brightness for "fade" type scenes.
The red LED value for Multicast.
The green LED value for Multicast.
The blue LED value for Multicast.
931251H
Installing the InformaCast Enabled Speaker
) in the following table shows which web page items will be defined
.
for more details.
Device Configuration
Table 2-15.
