2. On the Network page, enter values for the parameters indicated in
Note
Web Page Item
Stored Network Settings
Addressing Mode
Hostname
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
DHCP Timeout in seconds
VLAN Settings
VLAN ID (0-4095)
VLAN Priority (0-7)
Current Network Settings
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-12. Network Page Parameters
Description
Select either DHCP IP Addressing or Static Addressing by marking the appropriate radio
button. DHCP Addressing mode is enabled on default and the device will attempt to
resolve network addressing with the local DHCP server upon boot. If DHCP Addressing
fails, the device will revert to the last known IP address or the factory default address if no
prior DHCP lease was established. See
factory default settings. Be sure to click Save and Reboot to store changes when
configuring a Static address.
This is the hostname provided by the DHCP server. See the DHCP/DNS server
documentation for more information. Enter up to 64 characters.
Enter the Static IPv4 network address in dotted decimal notation.
Enter the Subnet Mask in dotted decimal notation.
Enter the Default Gateway IPv4 address in dotted decimal notation.
Enter the primary DNS Server IPv4 address in dotted decimal notation.
Enter the secondary DNS Server IPv4 address in dotted decimal notation.
Specify the desired time-out duration (in seconds) that the device will wait for a response
from the DHCP server before reverting back to the stored static IP address. The stored
static IP address may be the last known IP address or the factory default address if no
prior DHCP lease was established. Enter up to 8 characters. A value of -1 will retry
forever.
Specify the IEEE 802.1Q VLAN ID number. Enter up to 4 digits.
Note: The device supports 802.1Q VLAN tagging support. The switch port connected to
the device will need to be in "trunking mode" for the VLAN tags to propagate.
Specify the IEEE 802.1p VLAN priority level. Enter 1 digit. A value of 0 may cause the
VLAN ID tag to be ignored.
Shows the current network settings.
Shows the current Static IP address.
Shows the current Subnet Mask address.
Shows the current Default Gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
