CyberData 011395 Operation Manual page 38

Web Page Item
Button Settings
Button Installed
Relay On Button Press Duration
Button Lit when Idle
Button Brightness (0-255)
Play Ringback Tone
Prevent Call Termination
Blink Button LED on monitor call
InformaCast Settings
InformaCast Address
Singlewire Broadcast Strobe Settings
Priority
Scene
ADA Compliant
Slow Fade
Operations Guide
Table 2-6. Device Page Parameters (continued)
Description
Note: Not applicable. These settings are only available with the Talk-
Back Speaker.
When selected, the speaker is assumed to be wired to a push-to-talk
button. Button settings will be enabled and sensor settings will be disabled.
When not selected, the speaker is assumed to be wired to a sensor.
Sensor settings will be enabled and button settings will be disabled.
The length of time (in seconds) during which the relay will be activated
when the Call button is pressed. Enter up to 5 digits. A Relay on Button
Press Duration value of 0 will pulse the relay once when the Call button is
pressed.
When selected, the Call button LED is illuminated while the device is idle
(a call is not in progress).
The desired Call button LED brightness level. Acceptable values are 0-
255, where 0 is the dimmest and 255 is the brightest. Enter up to 3 digits.
When selected, the device will play a ringback tone (corresponds to
Ringback Tone on the Audiofiles page) out of the speaker while placing an
outbound call. The Ringback Tone will play until the call is answered.
When this option is enabled, a call cannot be terminated using the call
button.
Selecting this will cause the button LED blink during a monitor call.
Unselecting this will cause the speaker to give no indication that it is in a
monitor call.
Use this field to set the address of your Informacast server. This will
override any Informacast server addresses received via SLP or DHCP.
Enter "0.0.0.0" to use values received via SLP or DHCP. If using TFTP for
configuration, simply enter an IP address (eg. 10.0.1.195)If using HTTP for
configuration, enter the full URL to the path that contains the configuration
file. Do not input the file
name(eg.http://10.0.1.195:8081/InformaCast/resources/).
For up to 10 Singlewire pages, when a priority is specified for the page, a
corresponding strobe scene will be activated. The color may be selected
from the drop down menu, or customized by the user with the 0-255 scale.
Brightness is specified with a value between 0 and 100.
The following strobe settings will only appear if you are using the
Strobe Kit. If you are not using the Strobe Kit, you will not see the
strobe settings.
Indicates the priority of the Singlewire broadcast, with 1 the highest priority
and 10 the lowest.
Use this section to select the strobe flashing behavior for the Singlewire
Broadcast.
Strobe will blink ON at the specified brightness for 150ms then OFF for
350ms during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and
back to 0 over the course of about 3.5 seconds during the duration of the
event.
931251H
Installing the InformaCast Enabled Speaker
Device Configuration
CyberData Corporation
31
