The IP Endpoint Company



Multicast Speaker

Operations Guide

Part #011458, 011487, 011504, 011505

Document Part #932056A

for Firmware Version 22.0

CyberData Corporation

3 Justin Court

Monterey, CA 93940

(831) 373-2601

Need help?

Do you have a question about the 011458 and is the answer not in the manual?

Questions and answers

Summary of Contents for CyberData 011458

Page 1 The IP Endpoint Company  Multicast Speaker Operations Guide Part #011458, 011487, 011504, 011505 Document Part #932056A for Firmware Version 22.0 CyberData Corporation 3 Justin Court Monterey, CA 93940 (831) 373-2601...
Page 2 CyberData Corporation. This manual, and the products, software, firmware, and/or hardware described in this manual are the property of CyberData Corporation, provided under the terms of an agreement between CyberData Corporation and recipient of this manual, and their use is subject to that agreement and its terms.
Page 3 Potential safety hazards are identified in this manual through the use of words Danger, Warning, and Caution, the specific hazard type, and pictorial alert icons. Operations Guide 932056A CyberData Corporation...
Page 4 To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. GENERAL ALERT Warning The PoE connector is intended for intra-building connections only and does not route to the outside plant. GENERAL ALERT Operations Guide 932056A CyberData Corporation...
Page 5 Private Branch Exchange Power over Ethernet (as per IEEE 802.3af standard) RTFM Reset Test Function Management Session Initiated Protocol u-law A companding algorithm, primarily used in the digital telecommunication Unified Communications VoIP Voice over Internet Protocol Operations Guide 932056A CyberData Corporation...
Page 6 Contents Chapter 1 Multicast Ceiling Speaker Device Setup (Part #011458 and 011504) 1.1 Confirm that the Speaker is Operational and Linked to the Network ........1 1.2 Link/Activity LED ........................1 1.2.1 100 Mb LED ........................1 Chapter 2 Multicast Wall Mount Speaker Device Setup (Part #011487 and 011504) 2.1 Confirm that the Speaker is Operational and Linked to the Network ........2...
Page 7 1 Multicast Ceiling Speaker Device Setup (Part #011458 and 011504) 1.1 Confirm that the Speaker is Operational and Linked to the Network After connecting the speaker to the 802.3af compliant Ethernet hub, the LEDs on the rear of the speaker housing confirm that the speaker is operational and linked to the network.
Page 8 IP address (by default 10.10.10.10). This process will take approximately 80 seconds. 2.2.1 100 Mb LED • The yellow 100 Mb LED is illuminated when the network 100 Mb link to the speaker is established. Operations Guide 932056A CyberData Corporation...
Page 9 Note You may also download CyberData’s VoIP Discovery Utility program which allows you to easily find and configure the default web address of the CyberData VoIP products.   CyberData’s VoIP Discovery Utility program is available at the following website address: https://www.cyberdata.net/pages/discovery...
Page 10 Briefly pressing the RTFM button prompts the device to announce its IP address. Figure 3-2. RTFM Button (Ceiling Speakers) RTFM button Figure 3-3. RTFM Button (Wall Mount Speakers) RTFM button Operations Guide 932056A CyberData Corporation...
Page 11 Table 3-1. Factory Default Settings Parameter Factory Default Setting IP Addressing DHCP IP Address 192.168.1.23 Web Access Username admin Web Access Password admin Subnet Mask 255.255.255.0 Default Gateway 192.168.1.1 a. Default if there is not a DHCP server present. Operations Guide 932056A CyberData Corporation...
Page 12 The Home page provides device specific information such as Serial Number, Mac Address, and Firmware version. This page is designed as an initial landing page to provide general information on the status of the device. Figure 3-4. Home Page Operations Guide 932056A CyberData Corporation...
Page 13 Configure the Device Home Page If you are using the InformaCast Enabled Speaker (011504/011505), you will see the following: Figure 3-5. InformaCast enabled Device Operations Guide 932056A CyberData Corporation...
Page 14 The Device page allows for adjustment of settings that pertain to the physical device such as relay settings and time zone. Figure 3-6. Device Configuration Page If you are using the InformaCast Enabled Speaker (011504/011505), you will see the following: Figure 3-7. InformaCast enabled Device Operations Guide 932056A CyberData Corporation...
Page 15 Configure the Device Audio 3.4 Audio Figure 3-8. Audio Page Operations Guide 932056A CyberData Corporation...
Page 16 Configure the Device Network 3.5 Network The Network tab provides access to network-related settings. Assigning the device a static IP address or VLAN is done on this page. Figure 3-9. Network Page Operations Guide 932056A CyberData Corporation...
Page 17 SIP Client, and Autoprovisioning can be changed here. It is also possible to add additional CA certificates on this page. CA Certificates allow the device to authenticate servers that it contacts. Figure 3-10. SSL Page (1 of 2) Operations Guide 932056A CyberData Corporation...
Page 18 Configure the Device Figure 3-11. SSL Page (2 of 2) Operations Guide 932056A CyberData Corporation...
Page 19 A paging zone can consist of one or many CyberData multicast group-enabled products. There is no limit to how many endpoints can be in a given paging zone. Each multicast group is defined by a multicast address and port number.
Page 20 Configure the Device Audiofiles 3.8 Audiofiles The Audiofiles page is used to add custom audio to the board. User uploaded audio will take precedence over the audio files shipped with the device. Figure 3-13. Audiofiles Page Operations Guide 932056A CyberData Corporation...
Page 21 The Events page specifies a remote server that can be used to receive HTTP POST events when actions take place on the device. Figure 3-14. Events Page If you are using the InformaCast Enabled Speaker (011504/011505), you will see the following: Figure 3-15. InformaCast enabled Device Operations Guide 932056A CyberData Corporation...
Page 22 Here are example packets for every event: POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 197 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'> <event>POWERON</event> </cyberdata> POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 199 Content-Type: application/x-www-form-urlencoded <?xml version="1.0"...
Page 23 Configure the Device Events POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 205 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'> <event>CALL_TERMINATED</event> </cyberdata> POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 197 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'>...
Page 24 Configure the Device Events POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 234 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'> <event>RELAY_DEACTIVATED</event> </cyberdata> POST xmlparse_engine HTTP/1.1 Host: 10.0.3.79 User-Agent: CyberData/1.0.0 Content-Length: 234 Content-Type: application/x-www-form-urlencoded <?xml version="1.0" encoding="ISO-8859-1"?> <cyberdata NAME='CyberData VoIP Device' MAC='0020f70015b6'>...
Page 25 3.10 Terminus Terminus Cloud Control™ allows users to configure, monitor, and manage notification functions for CyberData's extensive VoIP product line, all from a single, easy-to-use platform. To learn more about Terminus Cloud Control™, go to https://www.cyberdata.net/pages/terminus. The Terminus page allows for configuration of settings related to Terminus Cloud Control™.
Page 26 Autoprov autoupdate, Autoprov at time, and Autoprov when idle options are available with either DHCP or a named server. The template is an xml file with all options set to default values. Figure 3-17. Autoprovisioning Page Operations Guide 932056A CyberData Corporation...
Page 27 CyberData strongly recommends that you do not upgrade the firmware when the device is likely to be in use. To upgrade the firmware of your device: 1. Download the latest firmware from the following CyberData web site, and locate your device: https://www.cyberdata.net/collections/sip https://www.cyberdata.net/collections/singlewire (for InformaCast Enabled devices) 2.
Page 28 Configure the Device Admin 3.13 Admin The administrator uses the Users List to create new accounts, assigning user names and passwords, and granting access to specific web pages. Figure 3-19. Admin Page Operations Guide 932056A CyberData Corporation...
Page 29 Play the "6" audio file wget --user admin --password admin --auth-no-challenge --no- check-certificate "https://10.10.1.138/audiofiles/" --quiet -O /dev/null --post-data "6=Play" Play the "7" audio file wget --user admin --password admin --auth-no-challenge --no- check-certificate "https://10.10.1.138/audiofiles/" --quiet -O /dev/null --post-data "7=Play" Operations Guide 932056A CyberData Corporation...
Page 30 "https://10.10.1.138/audiofiles/" --quiet -O /dev/null --post-data "restoringdefault=Play" Swap boot partitions wget --user admin --password admin --auth-no-challenge --quiet - O /dev/null --no-check-certificate "https://10.10.1.154/command" -- post-data "request=swap_boot_partition" a.Type and enter all of each http POST command on one line. Operations Guide 932056A CyberData Corporation...
Page 31 Support form at the following website: https://support.cyberdata.net/ The Support Form initiates a ticket which CyberData uses for tracking customer requests. Most importantly, the Support Form tells us which PBX system and software version that you are using, the make and model of the switch, and other important information. This information is essential for troubleshooting.
Page 32 SSL 11 Admin 22 Audio 9 Audiofiles 14 Terminus 19 Command Interface 23 Command Interface Post Commands 23 Warranty and RMA Information 25 Device 8 Events 15 Firmware 21 Home Page 6 Multicast 13 Network 10 Operations Guide 932056A CyberData Corporation...

This manual is also suitable for:

011487 011504 011505
