2.2.2.2 InformaCast Enabled Speaker with an External Device
In Figure
the speaker can be programmed to drive an external device such as an alert strobe. This external
device may also be addressed from a separate Unified Communication (UC) server.
Controlled Device
External Device
Such As
Such as an
Electric Door Strike
or
Electric Door Strike
Strobe Light
or LED Strobe Light
AC or DC
Power Source
AC or DC
Power Source
as Required by
an External Device
Operations Guide
2-5, when the InformaCast Enabled Speaker is called from a remote phone, the relay on
Figure 2-5. InformaCast Enabled Speaker with Alert Strobe
Solid State
Mechanical
OUT
Output Contacts
AC or DC rated
Output Contacts
Depending Upon
Controlled Device AC or DC-rated
Requirements
Depending Upon
External Device
Requirements
931251H
Speaker
AUX POWER (+)
(+24VDC @ 1A)
AUX POWER (-)
RELAY COM
RELAY NO
+5V OUT
N/C
J10
CLASS II WIRING
High PIV UltraFast
Switching Diode
or
Relay
IN
Installing the InformaCast Enabled Speaker
Device Configuration
AUX SPEAKER (-)
AUX SPEAKER (+)
GND
LINE OUT (-)
LINE OUT (+)
N/C
J9
+
-
DC
POWER SUPPLY
( )
MAX.
30 VDC @ 1A
