CyberData 011395 Operation Manual page 39

Web Page Item
Fast Fade
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
Power Settings
802.3AT Mode
Force 802.3AT Mode (NOT recommended)
Auxiliary Power Supply
Relay Settings
Activate Relay with DTMF Code
Relay Pulse Code
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Operations Guide
Table 2-6. Device Page Parameters (continued)
Description
Strobe will increase in brightness from 0 to the specified brightness and
back to 0 over the course of about 1.5 seconds during the duration of the
event.
Strobe will blink ON at the specified brightness for one second then OFF
for one second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per
second during the duration of the event.
Select the desired color (only one may be chosen).
How bright the strobe will blink when there is a Singlewire Broadcast. This
is the maximum brightness for "fade" type scenes.
The red LED value for the Singlewire Broadcast.
The green LED value for the Singlewire Broadcast.
The blue LED value for the Singlewire Broadcast.
Use this button to preview the strobe flashing behavior for the Singlewire
Broadcast Strobe Settings.
This device automatically detects if it is plugged into an 802.3AT (also
known as PoE Plus) power source. 802.3AT provides more power than
older 802.3AT power sources and allows this speaker to play audio at
higher volumes. If you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly, you can override the
automatic settings below.
Enable this option if you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly (not recommended).
This device can be connected to a +24VDC auxiliary power supply. Check
this box if this is how this speaker is being powered.
Activates the relay when the DTMF Activation Code is entered on the
phone during a SIP call with the device. RFC2833 DTMF payload types
are supported.
DTMF code used to pulse the relay when entered on a phone during a SIP
call with the device. Relay will activate for Relay Pulse Duration seconds
then deactivate. Activate Relay with DTMF Code must be enabled. Enter
up to 25 digits (* and # are supported).
The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.
Activation code used to activate the relay when entered on a phone during
a SIP call with the device. Relay will be active indefinitely, or until the
DTMF Relay Deactivation code is entered. Activate Relay with DTMF
Code must be enabled. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP
call with the device. Activate Relay with DTMF Code must be enabled.
Enter up to 25 digits (* and # are supported).
