Supplementary operating instructions for CANopen

1 Supplementary operating instructions for CANopen

1.1 About this pump

4
1.1 About this pump............................................................ 4
1.2 Control elements........................................................... 5
1.3 Electrical installation..................................................... 5
1.4 Emergency mode.......................................................... 7
1.5 Troubleshooting............................................................ 7
1.6 Accessories.................................................................. 8
1.7 Appendix....................................................................... 8
1.7.1 Object list for metering pump DULCO flex Control
DFXa, DFXa.............................................................. 8
1.7.2 Communication profile area 0x1000-0x1FFF............ 8
1.7.3 Manufacturer-specific profile area
0x2000-0x5FFF......................................................... 9
1.7.4 Device profile area 0x6000-0x9FFF........................ 13
1.7.5 Alarm action area for measurement devices
(404 )....................................................................... 18
1.7.6 EMERGENCY.......................................................... 18
1.7.7 Explanations of objects............................................ 20
1.7.8 Changing the CANopen node address (Node ID)... 21
1.7.9 Transfer rate (baud rate).......................................... 22
1.7.10 Calibration, explanations....................................... 22
1.7.11 Firmware update.................................................... 22
1.7.12 Data storage.......................................................... 22
1.7.13 Directives / standards complied with..................... 23
Metering pumps DULCO flex Control DFXa with CAN connector
differ from standard pumps in that they can be connected to a
CANopen bus system. A CAN pump DULCO flex Control DFXa
can be connected to a CANopen bus or used as a standalone unit.
Example:
Measurement value-dependent metering of sodium-calcium
n
hypochlorite into a swimming pool water circuit, in
operating mode, the pump being controlled by a controller.
A "CANopen" version of DULCO flex Control DFXa (Identity code
feature "Control type" = C or D) is designed for incorporation in a
CANopen system.
'CANopen'
