Hypertherm HyPrecision Predictive P-15 Operator's Manual page 90

5 – Preventive maintenance
1. Disconnect a tube by pulling the tube away from the clip.
2. Disconnect the tube from the push-to-connect fitting on top of the SMI by pushing up on the collar of the
fitting while pulling down on the tube.
3. Use the tube cleaning brush to clean the inner surfaces of the tube.
.
4. Rinse the tube with clean water.
5. Connect the tube to the push-to-connect fitting on top of the SMI.
6. Push the tube into the clip.
7. Do this procedure for all 4 tubes.
90
Before cleaning
HyPrecision Predictive waterjet pump Operator Manual 810120
After cleaning
