2 – Product description

Flow of water and hydraulic fluid

These diagrams show a typical installation.
1
2
Low-pressure water
1
Utility panel: C
Supply water from a water softener, a reverse
osmosis system, a well, or a public utility goes into
the pump.
2 Boost pump
Increases water pressure
3 Prefilter water gauge
4 Water filters
5 Postfilter water gauge
6 Water accumulator tank
7 Intensifier
36
3 5
4
UTTING WATER IN
HyPrecision Predictive waterjet pump Operator Manual 810120
9
6
13
14
High-pressure water
8
Attenuator
9 Utility panel: C
High-pressure water goes from the intensifier to
the cutting head.
10 Bleed-down valve
11 Utility panel: W
Low-pressure water goes to a drain.
12 Drip tray
13 Seal Maintenance Indicator (SMI)
14 Dirty water container
8
7
12
Seal Maintenance Technology™
UTTING WATER OUT
ASTE WATER OUT
10
11
