Make the connections to the utility panel

Compressed air is an energy source that can eject with force. Be careful when connecting to and
disconnecting from this energy source.
CAUTION
Water-cooled system
Do not connect the W
hoses can cause cooling water to back up into the system, which can cause damage to the
bleed-down valve and intensifier parts.
Air-cooled pump
If the C
exchanger before starting the motor, the hydraulic hoses can be damaged.
CAUTION
Do not tighten a fitting too much. The fitting can fail.
WARNING
To prevent dirty water from entering the bleed-down valve, install the W
that it is below the fitting on the pump.
CAUTION
Do not use an adjustable wrench on high-pressure fittings.
WARNING
The diagram on page 36 shows the flow of water through the pump system.
HyPrecision Predictive waterjet pump Operator Manual 810120
ASTE WATER OUT
hose and the C
OOLING IN OOLING OUT
hose and the C hose together. Connecting these
OOLING OUT
hose are not connected to the external heat
hose so
ASTE WATER OUT
