INSTALLATION AND cONNEcTION
Single axis module
X1A
Motor terminal block
U
Connection for three-phase
X1A
V motor ! Connect in phase for
correct direction of rotation.
W
Option terminal block
T1
Connection for PTC/KTY motor
X1B T2
B+
Connection for 24V DC brake
B-
Figure 11: View rear side of the device housing B/P
42
view rear side of the unit
Housing b / P
X1B
temperature monitoring
Double axis module
X1BB X1BA
Motor terminal block
U-A
V-A
X1A W-A
U-B
V-B
W-B
Option terminal block motor A
T1A
Connection for PTC/KTY mo-
tor temperature monitoring
X1BA T2A
BB+
BB-
Option terminal block motor b
T1B
Connection for PTC/KTY mo-
tor temperature monitoring
X1BB T2B
BB+
BB-
X1A
Motor output A
Motor output B
Connection for
24V DC brake
Connection for
24V DC brake
