Figure 12: View Rear Side Of The Unit - KEB COMBIVERT H6 Series Instructions For Use Manual

INSTALLATION AND cONNEcTION
Housing c/S
PE PE
X1A X1B
Device size 13...15
Housing G/W
X1B
X1A
U V W
Figure 12: View rear side of the unit
view rear side of the device
X1B
X1A
PE
Device size 16...19
PE
Housing E / U
X1B
X1A
PE
U V W
PE Connection for earthing
Motor terminal block
U
Connection for three-phase motor !
X1A
V Connect in phase for correct direction
W
Option terminal block
T1
Connection for PTC/KTY motor tem-
perature monitoring
X1B T2
B+
Connection for 24V DC brake
B-
PE
of rotation.
43
