MEcHANIcAL INSTALLATION

3.4.4 Dimensions and weights of modules with flat rear heat sink

300
150
50
Housing
B
C
E
G
Figure 4: Dimensions and weights of the axis modules
200 100
50 50
Module width in mm
50
100
200
300
50
198
Weight in kg
3.8
5.8
12.5
18
35
