Commissioning guide

16 Commissioning guide

16.1 Note

Only trained personnel following the safety regulations may commission the UNIGATE

16.2 Components

You will require the following components to commission the UNIGATE
®
UNIGATE
Connection cable from gateway to the process
Connector for Profibus connection to the Gateway
PROFIBUS cable (this cable is generally already installed on site!)
10..33 V DC power supply (DIN 19240)
Type file or GSD file and user manual (a sample file as well as the user manual can be ordered
separately or downloaded free of charge from our homepage at www.deutschmann.de).

16.3 Installation

®
The UNIGATE
CX-C4Map-PB module features protection type IP20 and is thus suitable for
switch cabinet use. The device is designed for snapping onto a 35 mm DIN-rail..
16.4 Dimensional drawing UNIGATE

16.5 Commissioning

It is essential that you perform the following steps during commissioning in order to ensure that
the module operates correctly:
50
Fieldbus-Gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
®
:
®
CX-C4Map-PROFIBUS DP
®
CX C4Map - PROFIBUS V. 1.0
®
.
28.9.20
