Open-Q™ 624A Development Kit
The development kit comes with Android software pre-programmed on the CPU board (SOM). Please contact
Lantronix for availability of display adaptors, camera modules, sensor boards, and other accessories:
sales@lantronix.com

3.5 Getting Started

This section explains how to setup the Open-Q 624A Development Kit and start using it.

3.5.1 Registration

To register the development kit and gain access to the Lantronix support site, please visit:
https://tech.intrinsyc.com/account/register.
To proceed with registration, the development kit serial number is required. The serial number can be found
on the label on the top side of the SOM. The label contains the Serial Number and WIFI MAC address.
Note: Please retain the Development Kit serial number for warranty purposes.
Refer to http://tech.intrinsyc.com/projects/serialnumber/wiki for more details about locating the development
kit serial number.
SOM serial number
Carrier board serial number
Figure 2: Development Kit label location

3.5.2 HDMI monitor connection

Connect an HDMI monitor to the HDMI output connector (29) with the HDMI cable (unless using the optional
LCD/touchscreen)

3.5.3 Powering Up the Development Kit

Connect the Power Adapter to the 12V DC Jack (11) and then press and hold the ON/OFF button (26) until
you see the Lantronix logo appear on the display (~3 seconds)
