Function
VBATT_CONN
BATT_ID_CONN
BAT_THERM_CONN
GND
Open-Q™ 624A Development Kit User Kit
Table 3-5 Battery Connector Pinout J300
Pin #
Description
J300[6, 5]
Battery Voltage
Battery Identification
J300[4]
Battery Thermistor
J300[3]
J300[1, 2]
Ground
Open-Q™ 624A Development Kit
Notes
Voltage must be 3.7V ~ 4.2V
Used for identification of battery pack
type. Typically connects to a pull-down
resistor in battery pack.
Used for the charger to monitor the
battery pack temperature.
23
