Table Of Contents - Intrinsyc LANTRONIX Open-Q 624A User Manual

Contents
1 Introduction
1.1 Purpose ___________________________________________________________ 6
1.2 Scope _____________________________________________________________ 6
1.3 Intended Audience ___________________________________________________ 6
2 Documents
2.1 Applicable Documents ________________________________________________ 7
2.2 Reference Documents ________________________________________________ 7
2.3 Terms and Acronyms _________________________________________________ 7
2.4 List of Figures _______________________________________________________ 9
2.5 List of Tables _______________________________________________________ 9
3 Open-Q™ 624A Development Kit
3.1 Introduction _______________________________________________________ 11
3.2 Development Platform Notice __________________________________________ 11
3.3 Anti-Static Handling Procedures _______________________________________ 11
3.4 Kit Contents _______________________________________________________ 11
3.5 Getting Started _____________________________________________________ 13
3.5.1
3.5.2
3.5.3
3.6 Development Kit Block Diagram ________________________________________ 14
3.7 Open-Q 624A SOM _________________________________________________ 15
3.7.1
3.7.2
3.7.3
3.8 Open-Q™ 624A Carrier Board _________________________________________ 18
3.8.1
3.8.2
3.8.3
3.8.4
3.8.5
3.8.6
3.8.7
3.8.8
3.8.9
3.8.10
3.8.11
3.8.12
3.8.13
Open-Q™ 624A Development Kit User Kit
Registration ____________________________________________________ 13
HDMI monitor connection __________________________________________ 13
Powering Up the Development Kit ___________________________________ 13
Hardware Features ______________________________________________ 16
SOM RF Interfaces for Wi-Fi and Bluetooth Antennas ____________________ 17
SOM RF Interface for GNSS Antenna ________________________________ 17
Open-Q™ 624A Carrier Board Expansion Connectors ___________________ 19
Dip switch S10 Configuration Options ________________________________ 19
Power Input ____________________________________________________ 20
SOM Power Source Switch S300 ___________________________________ 21
Battery Dip Switch S1 ____________________________________________ 21
Battery Connector J300 ___________________________________________ 22
Power Probe Header J86 __________________________________________ 24
Power Header via 20 Pin Connector J60 ______________________________ 24
External Battery Charging Header J26 _______________________________ 26
Debug Serial UART over USB J22 _________________________________ 28
Sensor IO Expansion Header J53 __________________________________ 29
Audio Input Expansion Header J50 _________________________________ 32
3.5mm Headphone and Microphone Jack J27 _________________________ 34
