Open-Q™ 2500 Development Kit User Guide

3.5 Getting Started

This section explains how to setup the Open-Q 2500 Development Kit and start using it.

3.5.1 Registration

To register the development kit and gain access to the Intrinsyc support site, please visit:
http://support.intrinsyc.com/account/register.
To proceed with registration, the development kit serial number is required. These serial numbers
can be found on the labels that are present on the SOM and carrier boards. The labels contain the
following information:
• SOM: Serial Number, WIFI MAC address
• Carrier: Serial Number
Note: Please retain the SOM and carrier board serial numbers for warranty purposes.
Refer to
http://support.intrinsyc.com/account/serialnumber
development kit serial number.

3.5.2 Configuration Switch Settings

The default configuration for the system configuration DIP switch S700 is for all switches to be open
or OFF. For details about other configurations, see section 3.7.2.

3.5.3 Powering Up the Development Kit

The development kit can be powered up by either using a DC power supply or by connecting a
battery on the connector J401. Select the desired power source using the switch S400 on the carrier
board. The green LED on the board is the power LED and should glow once the development kit is
powered. To see the debug logs, connect a serial debug cable on the J800 connector.
To power-up the board, perform the following exact steps below detailed below:
1. At a static-safe workstation, remove the development kit board carefully from the anti-static
bag.
2. Connect the Power Adapter to the 12V DC Jack and then press and hold the power button
until you see the Intrinsyc logo appear on the on-board display (~3 seconds).
3. Navigate using the touchscreen on the on-board display.

3.6 Open-Q 2500 SOM

The Open-Q 2500 SOM contains the core Snapdragon Wear 2500 architecture. Measuring in at
31.5mm x 15mm, the SOM is where all the processing occurs. It is connected to the carrier board via
12
Copyright Intrinsyc Technologies Corporation
for more details about locating the
Version 1.1
