3.7 Open-Q 624A SOM
The Open-Q 624A SOM measures 50mm x 46.5mm and is connected to the carrier board via three 100-pin
SOM to carrier board connectors (B2B Connectors). It provides the basic common set of features with minimal
integration efforts for end users to design into a product. For more details please refer to the Open-Q™ 624A
SOM Device Specification document (R-3).
It contains the following key components:
•
Qualcomm 624 (APQ8053-Lite) application processor
2GB LPDDR3 RAM, 4GB eMMC Flash
•
PMI8952 + PM8953 power management ICs (PMIC) for peripheral LDOs, boost regulators, battery
•
charging, and other house-keeping functions
•
Pre-certified 802.11ac 2x2 MU-MIMO Wi-Fi/BT Module with independent Bluetooth antenna port for
Bluetooth – Wi-Fi isolation
Integrated GNSS receiver for GPS, GLONASS, COMPASS location support.
•
Open-Q™ 624A Development Kit User Kit
50mm
Figure 4 Open-Q 624A SOM
Open-Q™ 624A Development Kit
46.5mm
15
