Intrinsyc LANTRONIX Open-Q 624A User Manual page 46

Pin # CAM0(J5)
7 VREG_L22_2P8
8 VREG_L22_2P8
9 VREG_L6_1P8
10 VREG_L6_1P8
11 GPIO_CAM_MUTE_STATUS
(APQ_GPIO87)
12 CAM0_FLASH_EN
(APQ_GPIO33)
13 CAM1_RST_N
(APQ_GPIO40)
14 CAM1_STANDBY_N
(APQ_GPIO39)
15 GPIO_30_CCI_I2C_SCL0
(APQ_GPIO30)
16 GPIO_29_CCI_I2C_SDA0
(APQ_GPIO29)
17 GPIO_26_CAM_MCLK0
(APQ_GPIO26)
18 CAM0_FLASH_TRIG
(APQ_GPIO34)
19 GND
20 MIPI_CSI0_LANE0_N
21 MIPI_CSI0_LANE0_P
22 GND
Open-Q™ 624A Development Kit User Kit
CAM1(J4)
MB_ELDO_CAM1_VCM
MB_ELDO_CAM1_VCM
VREG_L6_1P8
VREG_L6_1P8
GPIO_CAM_MUTE_STATUS
(APQ_GPIO87)
CAM1_FLASH_EN
(APQ_GPIO33)- Not
connected by Default
CAM2_RST_N
(APQ_GPIO129)
CAM2_STANDBY_N
(APQ_GPIO130)
GPIO_30_CCI_I2C_SCL0
(APQ_GPIO30)
GPIO_29_CCI_I2C_SDA0
(APQ_GPIO29)
GPIO_27_CAM_MCLK1
(APQ_GPIO27)
CAM0_FLASH_TRIG
(APQ_GPIO34)- Not
connected by Default
GND
MIPI_CSI1_LANE0_N
MIPI_CSI1_LANE0_P
GND
Open-Q™ 624A Development Kit
Description
Power output. Connected to
PM8953 VREG_L22 regulator
(150mA) on CAM0, and
onboard LDO (300mA) on
CAM1. Default is +2.80.
Power output. Connected to
PM8953 VREG_L6_1P8.
Default is +1.8V. Maximum
current 300mA
Default Use is for camera
shutter closed indication.
Connected to GND on Lantronix
Camera Adaptor Boards.
Output. Default use is for
camera flash strobe enable
Output. Default use is for
camera reset
Output. Default use is for
camera standby
Output. Default use is for
camera CCI0 I2C clock interface
Input / output. Default use is for
camera CCI0 I2C data interface
Output. Default use is for
camera master clock. Maximum
24MHz
Output. Default use is for
camera flash strobe trigger
Ground
Input. MIPI CSI0 / CSI1data
lane 0
Input. MIPI CSI0 / CSI1 data
lane 0
Ground
