Unlocking - Permobil Explorer Mini Service Manual

Explorer Mini Adjustments - Locking and unlocking the Explorer Mini
5.2.2

Unlocking

The Explorer Mini is unlocked with the steps below. Step 4 and 5 must
be done swiftly, otherwise the procedure gets interrupted and you must
start again from step 2.
1. Remove the tray top.
2. Make sure that the Explorer Mini is turned on.
3. The LEDs of the maximum speed indicator will flash repeatedly.
4. Push the joystick forward until a beep sounds.
5. Pull the joystick backward until a beep sounds.
6. Release the joystick. A beep sounds and the Explorer Mini is
unlocked and can be driven.
Figure 139. Procedure for unlocking.
72
