Explorer Mini
NOTICE
Prevent sunlight
Make sure that the Explorer Mini and the charger are not positioned in
immediate sunlight during charging.
NOTICE
Automatically locked for driving
The Explorer Mini is automatically locked for driving during charging. If it is still
possible to drive during charging, contact your dealer.
1. Press the on/off button to turn off the power.
2. Connect the charging connector to the charging socket of the
Explorer Mini.
3. Connect the charger contact to the wall socket.
4. Charge the batteries.
5. Disconnect the charger contact from the wall socket.
6. Disconnect the charging connector from the charging socket of the
Explorer Mini.
52
Repairs - Batteries
Figure 101. Connect the charging connector to the
charging socket.
