5.2 Locking and unlocking the Explorer
Mini
The Explorer Mini can be locked to prevent other users from driving it.
When the Explorer Mini is locked it cannot be driven before it is
unlocked again. An adult must lock or unlock the wheelchair.
5.2.1

Locking

The Explorer Mini is unlocked with the steps below. Step 3 and 4 must
be done swiftly, otherwise the procedure gets interrupted and you must
start again from step 1.
1. Make sure that the Explorer Mini is turned on.
2. Press and hold the on/off button for one second until a beep sounds.
3. Push the joystick forward until a beep sounds.
4. Pull the joystick backward until a beep sounds.
5. Release the joystick. A beep sounds and the Explorer Mini is locked
for driving.
Adjustments - Locking and unlocking the Explorer Mini
Figure 137. The Explorer Mini can be locked to prevent
other users from driving it.
Figure 138. Procedure for locking.
