Explorer Mini
7. Remove the four screws and washers that attach the table to the
bracket.
8. Loosen the two screws from the key slots on the bracket. Do not
remove the screws. They keep the table in place when the four
screws and washers are removed from the table.
9. Carefully slide the table backward and lift it off the bracket. The two
screws are released from the key slots on the bracket when the table
is lifted off. The two screws remain attached on the table.
Repairs - Table and backrest unit
Figure 22. Remove the four screws and washers.
Figure 23. Loosen the two screws.
Figure 24. Slide the table backward and lift it off the
bracket.
