Explorer Mini
5. Remove the screw from the cover on the UniTrack® at the front of
the base module.
6. Fold the cover upward and remove it.
7. Remove the screw from the cover on the UniTrack® at the rear of
the base module and remove the cover. If necessary, use a
screwdriver or pliers to loosen the cover from the UniTrack®.
26
Repairs - Base module
Figure 36. Remove the screw from the cover on the
UniTrack® at the front of the base module.
Figure 37. Fold the cover upward.
Figure 38. Remove the cover.
Figure 39. Remove the cover on the UniTrack® at the
rear of the base module.
