Info: Frequent updates of the Power Debugger firmware are provided in order to improve its features,
and to provide support for new MCUs. If required, refer to Appendix A to upgrade the Power Debugger
firmware.
Kit Contents
The Power Debugger kit contains:
•
One Power Debugger unit with plastic back-plate
•
Two USB cables (1.5m, high-speed, Micro-B)
•
One adapter board containing 50-mil AVR, 100-mil AVR/SAM, and 100-mil 20-pin SAM adapters
•
One IDC flat cable with 10-pin 50-mil connector and 6-pin 100-mil connector
•
One 50-mil 10-pin mini squid cable with 10 x 100-mil sockets
•
20 x 100-mil separable strap cables
Figure 1. Power Debugger Kit Contents
©
2020 Microchip Technology Inc.
User Guide
Power Debugger
DS40002201A-page 2
