To do:
•
3.1.13.2 Connect Interface to Terminal
To do:
•
•
•
©
2020 Microchip Technology Inc.
Enable Synchronous mode with timestamps in the USART Configuration window
Open the configuration panel
Add a Terminal view to the Visualizer
Drag the source connector from the interface in the DGI Control Panel into the sink for the Terminal
to make a connection
User Guide
Power Debugger
Detailed Use Cases
DS40002201A-page 28
