Figure 2-2. WFI32-IoT Board (EV36W50A) – Bottom View
Power Distribution
Switch (U100)
USB-to-UART Serial
Converter (U202)
Temperature
Sensor (U402)
Secondary
Oscillator (Y400)
2.1

Kit Contents

The EV36W50A (WFI32-IoT board) kit contains the following:
• A WFI32E01PC module mounted on the WFI32-IoT board
• A Type-A male to Micro-B USB cable
Note: If any of the above items are missing in the kit, go to
Sales office. In this user guide, there is a list of Microchip offices for sales and services provided on the last page.
©
2022 Microchip Technology Inc.
and its subsidiaries
support.microchip.com or contact your local Microchip
User Guide
EV36W50A
Kit Overview
Voltage Regulator (U104)
Li-Ion/LiPo
Charger (U101)
PKOB4 Main
Controller (U300)
DS50003262A-page 7
