// Clear the flag
UCSR0A = (1 << TXC0);
}
int main(void)
{
// PORTB5 to output
DDRB = (1 << 5);
// LED OFF
PORTB = 0;
led_on = 0;
// Enable Pin-change interrupt
PCICR = (1 << PCIE0);
PCMSK0 = (1 << PCINT7);
// USART0
// Baud trivial in synchronous mode
UBRR0 = 0x0FFF;
// Enable XCK for master clock outout
DDRD |= (1 << 4);
// Enable USART transmitter
UCSR0B |= (1 << TXEN0);
// Synchronous mode
UCSR0C |= (1 << UCSZ01) | (1 << UCSZ00) | (1 << UMSEL00);
// Interrupts on
sei();
while(1)
// Sleep
set_sleep_mode(SLEEP_MODE_IDLE);
sleep_mode();
// Woken up
if(send_message) {
// Send a message
const
if
else
while
// Send the ticker value
usart_send(ticker + '0');
usart_send('\n');
// Sent
send_message = 0;
}
}
}
To do:
•
•
•
3.1.13.1 Enable USART Interface
To do:
•
•
©
2020 Microchip Technology Inc.
{
char* pmessage;
(led_on)
pmessage = message_on;
pmessage = message_off;
(*pmessage)
usart_send(*pmessage++);
Build the project/solution (F7)
Program the application into the target device using Start Without Debugging (Ctrl+Alt+F5)
Switch to Data Visualizer to see the results
Check the USART checkbox
Open the USART Configuration dialog by pushing the gear button next to the USART checkbox
