A slider control needs to have some configuration parameters.
To do: Select the slider element and set its properties:
•
Maximum = 500
•
Minimum = 100
A segment display control can now be added to the dashboard.
To do:
•
Select the Edit checkbox
•
Open the Elements tab
•
Drag a Segment Display element onto the dashboard
©
2020 Microchip Technology Inc.
User Guide
Power Debugger
Detailed Use Cases
DS40002201A-page 50
