Ross Ultricore RCP-ME User Manual page 87

Area
Configuration Breakaway Reset
Breakaway Warning
Mode
Panel Locked
Machine Control
Enabled
Machine Control Level
Virtual Routing
Enabled
Comms Retry Delay
Factor
Protect Mode
Clear Protect(s)
Return to Home Menu
Load Factory Defaults
RCP-ME User Guide (v4.0)
Table 16.5 Configuration Tab
Item Parameters
Selected
Cleared
Current
Default
Selected
Cleared
Selected
Cleared
#
Selected
Cleared
#
Block Other
Panels
Block All
Panels (Lock)
Selected
Cleared
Selected
Cleared
Selected
Cleared
Description
Return to the default breakaway after every switch.
The default is Breakaway 1.
Disables this feature
if there is a level mismatch compared to the current
breakaway, a breakaway warning is shown when
displaying the status
if there is a level mismatch compared to the default
breakaway (Breakaway 1), a breakaway warning is
shown when displaying the status
Locks the panel buttons
Unlocks the panel buttons
Uses machine control to provide reciprocal
switching of RS-422 signals
Disables this feature
Specify a router level for machine control
Enable virtual routing. Virtual routing requires an
NK-VRC in an Ross NK series router system.
Virtual routing must be enabled for the RCP-ME to
function with an Ultrix router or Ultricore Central
Controller.
Disables this feature
Specifies a retry delay factor in milliseconds.
Systems require different retry times depending on
the transfer of requests and responses between
modules.
A value of 50 to 100ms is recommended.
The protected destination and level(s) cannot be
switched to another source by other remote control
panels or control devices.
The protected destination and level(s) can be
switched to another source on the current remote
control panel.
The protected destination and level(s) cannot be
switched to another source by any control device
Clears all protects from the panel
Protects are not cleared from the panel
Forces the panel to its home menu configuration
Panel will continue showing its current menu/page
Loads the factory defaults of the panel. This box is
cleared immediately upon sending to a panel.
Panel default layout will not be loaded
DashBoard Interface Overview • 87
