Examples
To select SRC HD1 to DEST VTR3
1. Select the destination by pressing
VTR
HD CAM
IN
1 2 3
2. Press .
3
VTR
HD CAM
IN
1 2 3
3. Select the source by pressing
VTR
HD CAM
IN
1 2 3
4. Press .
1
VTR
HD CAM
IN
1 2 3
To select SRC VTR2 to DEST SAT2
1. Select the destination by pressing
VTR
HD CAM
IN
1 2 3
2. Press .
2
VTR
HD CAM
IN
1 2 3
3. Select the source by pressing
VTR
HD CAM
IN
1 2 3
4. Press .
2
VTR
HD CAM
IN
1 2 3
