  • Page 1 TouchDrive and Carbonite Black Control Panel Guide v1.2...
  • Page 2 6. We will keep our promises. 7. We will treat the competition with respect. ii • Thank You For Choosing Ross — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 3 Product may require specific equipment, and/or 9. Do not defeat the safety purpose of the installation procedures to be carried out to polarized or grounding-type plug. A TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Document Information • iii...
  • Page 4 1RU Audio Breakout Module. iv • Document Information — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 5 Return packing, shipping, and special handling costs are the responsibility of the customer. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Document Information • v...
  • Page 6 After Hours (+1)613-349-0006 Emergency: You can also contact Ross Video for more information on the environmental E-Mail (Support): techsupport@rossvideo.com performances of our products. vi • Document Information — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 7 Video Community site (discussions.rossvideo.com/) • TouchDrive webhelp — visit help.rossvideo.com/switcher-panels • Software Licenses (4841DR-502) — third-party software licences • Carbonite Multilingual Safety Information (4802DR-503) — translated product safety information TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Document Information • vii...

  • Page 8: Table Of Contents

    Recalling Memories..........24 Custom Controls..............26 Recording Custom Controls........26 Specifications..........39 Editing a Custom Control........27 Hardware Weights..............39 Running a Custom Control........28 Panel Shortcuts..............28 Environmental Characteristics..........39 Network Ports.................39 Power Consumption — Panel..........39 viii • Contents — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 9 Index...........40 TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Contents • ix...

  • Page 10: Control Panel Overview

    The 3-knob menu is used to access the legacy Press and hold the button to select a different menu system of the switcher, as well as some aux bus. 10 • Control Panel Overview — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 11: Positioner

    2. Global Memory — These buttons are used to store or recall memories to one or more TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Control Panel Overview • 11...

  • Page 12: Cb9 Control Panel

    12. Video Source Buses — These buses are broken into the Preset, Program, and Key/Aux/Custom Control buses. The Preset Figure 2: CB9 Control Panel bus is the bottom row of source buttons and 12 • Control Panel Overview — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 13 11. Transition Area — These buttons are used to select which video source buses will be included in the next transition and what TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Control Panel Overview • 13...

  • Page 14: Menu Interfaces

    3-knob menu to the wipe pattern. assigned to them. If you select a source button that an external device is assigned to, the 14 • Menu Interfaces — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 15 TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Menu Interfaces • 15...

  • Page 16: Panel Operation

    The Key bus can then be assigned to other resources on the switcher, such as an Aux. The ME button turns white and the mnemonics on the row list all the resources 16 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 17: Video Sources

    The buttons on each bus of the panel row are is reset, but not when a factory default or switcher set is used to select the source that is mapped to that recalled. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 17...

  • Page 18: Transitions

    Press and hold DISS and press Flash on the row point, the next transition starts from the control menu to select a WhiteFlash transition. transition limit point and goes forward to 18 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 19: To Perform A Transition On Touchdrive (No Memory Area)

    ENTER. The rate is shown on the display on the Transition area. • Key Only — press KEY RATE and use the keypad to enter a new rate, in frames, TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 19...

  • Page 20: To Perform A Transition On Carbonite Black

    2. In the Transition area, select the elements perform. you want to include with the transition. If • Background you are including multiple elements, press and hold the first button and press the other 20 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 21: To Override The Pre-Delay Setting

    6. If a pre-delay has been set, and the ROLL CLIP button is active, the switcher will apply TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 21...

  • Page 22: To Set Up A Key On Touchdrive

    Use DashBoard to set the attributes that you want to include. Note: The information will change depending on the type of key selected. 22 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 23: Storing Memories

    ROW selects MiniME ™ the memory for. • ALL — press ALL to include all available resources in the memory. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 23...

  • Page 24: Recalling Memories

    MiniME ™ , or MultiScreen to store the memory for, and then use the mnemonic buttons to select the bank and register to store the memory in. 24 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 25 • none — when none of the buttons are to select the bank and register you want to selected the memory is recalled in the recall the memory from. mode that was stored with it. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 25...

  • Page 26: Custom Controls

    If events have already been recorded to a custom • 2 — ME 1 control, an * is shown next to the CC number. • 3 — ME 2 26 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 27: Editing A Custom Control

    The custom control will have an * next to the number. 4. Use the Func knob to select where and how you want to edit the custom control. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 27...

  • Page 28: Running A Custom Control

    To Run a CC on Carbonite Black key bus. 1. Press the CC BNK X user button for the custom control bank you want to run a cc 28 • Panel Operation — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 29 Press Reset Key on the row control menu. Carbonite Black — reset a single keyer. Press and hold the KEY X SEL button for the keyer you want to reset. Press RESET. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Operation • 29...

  • Page 30: Panel Setup

    6. Click a Send Logs to Frame button to select double-click Configuration > Date Time. whether panel logs are sent to the frame (Enabled) or not (Disabled). Sending panel 30 • Panel Setup — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 31: Touchscreen Configuration

    Don't forget that you can assign sources to the shifted double-click Configuration > Alarms bus by pressing and holding the shift button and pressing Enables the source button. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Setup • 31...

  • Page 32: Control Panel Button Inserts

    7. Delete the current position as follows: a) Tap the mnemonic button for the map position you want to delete the source from. 8. Tap Exit BusMap. Figure 7: Inserting Film 32 • Panel Setup — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 33: Mnemonics

    3. Click the Icon button for the source you want to customize the mnemonics for and click the icon you want to use. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Panel Setup • 33...

  • Page 34: Personality

    Next Button Secondary Function Note: Not available on the TouchDrive. 34 • Personality — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 35: Touchdrive Software Upgrade

    7. Wait for the DashBoard pages to come back up. This may take a few minutes. To Upgrade DashBoard on the Control Panel Upgrade the DashBoard control system software on the control panel. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — TouchDrive Software Upgrade • 35...

  • Page 36: Diagnostics

    All settings except ethernet are returned to the Diagnostic Tests (Diag Tests on Carbonite default value. Black) > P-LEDs Test. All the buttons and indicators on the control panel cycle through different colors. 36 • Diagnostics — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 37: To Factory Default The Panel

    1. From the tree view for the control panel, double-click Configuration > Upgrade PMC & PCH. 2. Click Upgrade PMC and PCH. 3. Click Yes. 4. Wait for the upgrade to complete. TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Diagnostics • 37...

  • Page 38: Calibration

    3. Move each fader from one limit to the next a few times. Do not push the fader hard when it reaches the limit. 4. Press MENU to save the calibration information. 38 • Calibration — TouchDrive and Carbonite Black Control Panel Guide (v1.2)

  • Page 39: Specifications

    • RossTalk — 7788 • SLP — 427 • SSH — 22 • TFTP — 69 • TSL — 5727 • Web Server 1 — 80 • Ultritouch — 5255 TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Specifications • 39...
  • Page 40 DashBoard Menus Diagnostics Copy Logs Personality Double-Press Rate DblPrs Speed Double-Press Rate ME Select NEXT Button Editing Custom Controls PMC Upgrade Elite Control Panels Ports, Network Positioner Pre-Delay Override 40 • Index — TouchDrive and Carbonite Black Control Panel Guide (v1.2)
  • Page 41 Video Source Buses Touchscreen Configuration Video Sources Trans Preview 18–20 External Transition Area Follows Transitions 18–21 Internal Aborting Selecting Auto Transition 18–20 Selecting on Carbonite Black 18–20 Selecting on Elite TouchDrive and Carbonite Black Control Panel Guide (v1.2) — Index • 41...
