5. Click .
OK

Editing a Configuration File

Any saved configuration files can be accessed and opened via the File Navigator pane in the DashBoard window.
You can also open a saved configuration file, make changes to it, save it, and then send it to a panel.
To edit a saved configuration file
1. In the File Navigator pane, navigate to the saved configuration file that you want to open.
2. Double-click the icon for the file.
The saved Panel Config interface displays in the right pane of the DashBoard window with the name of the file
displayed in the interface tab.
3. Update the settings in the Panel Config interface as required.
4. Follow the procedure "Sending a Configuration File to a Device" on page 74.

Sending a Configuration File to a Device

When you have made changes to the configuration of a panel, the changes are not activated in that panel until those
changes are sent to the hard panel. You can also choose to send the same configuration to multiple panels without
using the File Navigator pane in DashBoard.
To send the current configuration to a panel
1. Configure your panel using the tabs and options in the Panel Config interface.

If you want to send the default configuration to a panel, open the default configuration file from the File
Navigator pane.
2. Click
Send Configuration
The Send Configuration dialog opens.
3. From the list in the left column of the dialog, select the tab settings that you want to send to the device.
4. In the Select Devices list, select the panel to which you want to send the current configuration.
5. Click .
Send
6. In the Basic Tree View in the DashBoard window:
a. Right-click the panel node.
b. Select
Reload
The panel is reloaded with the new configuration.
74 • Managing Panel Configurations
.
.
RCP-ME User Guide (v4.0)
