3. In the Configuration section, select the Panel Locked check box.
4. Send the current configuration file to the device (see "To send the current configuration to a panel" on
page 74).
The RCP-ME is locked.

If a panel button is assigned, it can be pressed to unlock the RCP-ME.
LOCK
To lock the RCP-ME using a panel lock button
• Press the panel
LOCK
The panel button illuminates. A brief KEY LOCK message is shown on the screen.
LOCK
Every button on the RCP-ME becomes inactive except for the panel
To unlock the RCP-ME using a panel lock button
• If you want to unlock the RCP-ME, press the panel
The panel button switches off. A brief KEY UNLOCK message is shown on the screen.
LOCK
To lock the RCP-ME using a protect button
• Hold the
PROTECT
A brief KEY LOCK message is shown on the screen.
If a panel button is assigned to the RCP-ME, this button illuminates.
LOCK
Every button on the RCP-ME becomes inactive, except for the
assigned.
To unlock the RCP-ME when locked by a protect button
• If the RCP-ME is locked using a protect button and you want to unlock it, hold the protect button or press the
panel lock button, if assigned.
A brief KEY UNLOCK message is shown on the screen.

The button does not illuminate.
PROTECT

Protecting a Destination

You can use a protect button to prevent switching of critical crosspoints by others. The protect function ensures that
the selected destination can only receive the selected source across the selected levels. Once protected, the selected
levels on a destination cannot be switched by other remote control panels (or by the same remote control panel if
Block All Panels is selected). The source is not protected and can be freely routed to other destinations if required.
You can protect any number of destinations.
You can set the extent of protection that is used via DashBoard, such as protected against other remote control
panels or protected against all remote control panels (see "Locking an RCP-ME" on page 62).
To protect a destination
1. Make the switch.
2. Press the
PROTECT
The button and the protected crosspoint are illuminated. The screen indicates that a protect is in
PROTECT
place by showing the protection indicator at the bottom left of the screen.
RCP-ME User Guide (v4.0)
button.
button for 3 seconds.
button.
SRC: Server 2
1 2 3 4
DST: Monitor
L
Figure 10.1 Protected Crosspoint and Protection Indicator
button.
LOCK
button.
LOCK
button and panel
PROTECT
button, if
LOCK
Protects and Locks • 63
