Connecting to the Routing System
Once you have established communication between the DashBoard client and the RCP-ME, you will need to
connect the panel to the routing system. You can specify multiple devices for the RCP-ME to communicate with,
but the panel will only connect to one device at a time (as indicated by the read-only Connected check box beside
the IP Address for the device). The RCP-ME will attempt to connect to the first device listed in the table, and move
to the next device in the table if communication could not be established.
For More Information on...
• establishing communications with an Acuity production switcher, refer to the Acuity and Auxiliary Control
Panels Setup Sheet.
To connect the RCP-ME to the routing system
1. Display the Connection Editor as outlined in the procedure "To open the RCP-ME Connection Editor" on
page 22.
2. Locate the Servers to Connect to table.
3. In the first row of the table, use the IP Address column to specify the IP Address of the NK-NET, NK-IPS,
Ultrix router, or Ultricore Central Controller that the RCP-ME will communicate with.
4. Send the current configuration file to the device (see "To send the current configuration to a panel" on
page 74).
Changing the Device Details
Once the RCP-ME is added to the Tree View in DashBoard, you can update the panel details, such as the name it
displays in the tree view, assign it to a group in your routing system, and provide additional identification details.
To change the details for the RCP-ME
1. Display the Connection Editor as outlined in the procedure "To open the RCP-ME Connection Editor" on
page 22.
2. Locate the Device Details area in the top-right corner of the interface.
3. In the Device Details area, click inside the field that you want to change.
4. Enter the information as required.
5. Press .
Enter
6. Send the current configuration file to the device (see "To send the current configuration to a panel" on
page 74).

You should save the current configuration file regularly.
Default Configuration
Every panel leaves the factory with a default configuration. This default configuration is viewed by opening the
editor tab for the device in DashBoard. The parameters for the default configuration are stored within the RCP-ME.
The default configuration may be loaded at any time you wish to return to the factory settings. Refer to the section
"Resetting Devices" on page 27 for more information.
RCP-ME User Guide (v4.0) Getting Started • 25
