Specifications
163 ±1 mm [6.4 ±0.04 in]
Illustration 7.63 IP21 X1 External Fan 1
Illustration 7.64 IP21 X1 External Fan 1, 3D View
MG80C502
Design Guide
151 ±2.5 mm [5.9 ±0.1 in]
278 ±2.5 mm [10.9 ±0.1 in]
162 ±2.5 mm [6.4 ±0.1 in]
429 ±2.5 mm [16.9 ±0.1 in]
501 ±2.5 mm [19.7 ±0.1 in]
Danfoss A/S © 10/2016 All rights reserved.
196 ±2 mm [7.7 ±0.1 in]
190 ±2 mm [7.5 ±0.1 in]
75 ±2.5 mm [3.0 ±0.1 in]
7
7
89
