Specifications
X1 Mains 16mm
X2 Drive 16mm
X3/X4 Capacitor disconnect 10mm
A/B Temperature 2.5mm
F1
F2
PE M8
145 ± 1 mm [5.7 ± 0.04 in]
9 ± 1 mm [0.4 ± 0.04 in]
Illustration 7.19 IP20 X3 External Fan 2
Illustration 7.20 IP20 X3 External Fan 2, 3D View
MG80C502
Design Guide
2
2
2
2
460 ± 2.5 mm [18.1 ± 0.1 in]
233 ± 1 mm [9.2 ± 0.04 in]
9 ± 1 mm [0.4 ± 0.04 in]
547 ± 2.5 mm [21.5 ± 0.1 in]
586 ± 2.5 mm [23.1 ± 0.1 in]
589 ± 2.5 mm [23.2 ± 0.1 in]
629 ± 2.5 mm [24.8 ± 0.1 in]
Danfoss A/S © 10/2016 All rights reserved.
330 ± 2.5 mm [13.0 ± 0.1 in]
145 ± 1 mm [5.7 ± 0.04 in]
7 7
67
