Danfoss VLT AHF 005 Design Manual page 12

Introduction to Harmonics a...
1
2 2
0.
0
-
-
0
1
0.
0
-
-
0
Illustration 2.3 Sinusoidal Waveforms
The integer multiples of the fundamental frequency ω1 are
called harmonics. The RMS value of a non-sinusoidal
waveform (current or voltage) is expressed as:
h
max
∑
2
I = I
RMS (h)
h = 1
The number of harmonics in a waveform gives the
distortion factor, or total harmonic distortion (THD). The
THD is given by the ratio of RMS of the harmonic content
to the RMS value of the fundamental quantity, expressed
as a percentage of the fundamental:
h
max
∑
THD =
h = 2
Using the THD, the relationship between the RMS current
I and the fundamental current I
RMS
I = I × 1 + THD
RMS 1
The same applies for voltage.
10
1 2
1 2
2
I
h
× 100 %
I
1
can be expressed as:
1
2
Danfoss A/S © 10/2016 All rights reserved.
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
3 4
3 4
The true power factor PF (λ) is:
P
PF =
S
In a linear system, the true power factor is equal to the
displacement power factor:
PF = DPF = cos ϕ
In non-linear systems, the relationship between power
factor and displacement power factor is:
PF =
1 + THD
Reactive power decreases the power factor and harmonic
loads. A low power factor results in a high RMS current
that produces higher losses in the supply cables and
transformers.
In the power quality context, the total demand distortion
(TDD) term is often encountered. The TDD does not
characterize the load, but it is a system parameter. TDD
expresses the current harmonic distortion in percentage of
the maximum demand current I
5 6
5 6
DPF
2
.
L
7
7
MG80C502
