AHF filter type
Mains voltage AHF
230 V
380–415 V
440–480 V
500 V
525–575 V
600 V
690 V
Table 5.11 Control Voltage Setting, IP21/NEMA1 Kit with
5 5
Contactor

5.3.2 Backplate for IP20

To avoid false airflow when mounting the filter on rails,
order a backplate. For more information, see
chapter 4.1.4 Ventilation and Cooling Requirements.
Ordering number
130B3283
130B3284
130B3285
130B3286
130B3287
130B3288
Table 5.12 Selection Table, Backplate
46
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Terminals
Wire connctions to transformer
X6–X12
X6–X13
X6–X14
X6–X14
X6–X15
X6–X16
X6–X17
Backplate
X1
X2
X3
X4
X5 and X6
X7 and X8
