Danfoss VLT AHF 005 Design Manual page 134

Specifications
Filter
current
rating
[A]
15
20
24
29
36
50
58
7 7
77
87
109
128
155
197
240
296
366
395
Table 7.23 600 V, 60 Hz
1) Specified type is a UL requirement.
132
Maximum
Fuses
fuse size
[A] (type)
Class J, 600 V AC, rated breaking
35
capacity 100 kA
Class J, 600 V AC, rated breaking
35
capacity 100 kA
Class J, 600 V AC, rated breaking
50
capacity 100 kA
Class J, 600 V AC, rated breaking
50
capacity 100 kA
Class J, 600 V AC, rated breaking
60
capacity 100 kA
Class J, 600 V AC, rated breaking
80
capacity 100 kA
Class J, 600 V AC, rated breaking
100
capacity 100 kA
Class J, 600 V AC, rated breaking
125
capacity 100 kA
Class J, 600 V AC, rated breaking
150
capacity 100 kA
Class J, 600 V AC, rated breaking
200
capacity 100 kA
Class J, 600 V AC, rated breaking
250
capacity 100 kA
Class J, 600 V AC, rated breaking
300
capacity 100 kA
Class J, 600 V AC, rated breaking
350
capacity 100 kA
Class J, 600 V AC, rated breaking
400
capacity 100 kA
Class J, 600 V AC, rated breaking
500
capacity 100 kA
Class J, 600 V AC, rated breaking
600
capacity 100 kA
Class J, 600 V AC, rated breaking
600
capacity 100 kA
Danfoss A/S © 10/2016 All rights reserved.
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Filter
1) current
rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
395
Table 7.24 500–690 V, 50 Hz
In applications where filters are paralleled, it might be
necessary to install fuses in front of each filter and in front
of the frequency converter.
Maximum
Fuses
fuse size
[A] (type)
35 gRL 690 V AC
35 gRL 690 V AC
50 gRL 690 V AC
50 gRL 690 V AC
63 gRL 690 V AC
80 gRL 690 V AC
125 gRL 690 V AC
160 gRL 690 V AC
250 gRL 690 V AC
250 gRL 690 V AC
250 gRL 690 V AC
315 gRL 690 V AC
350 gRL 690 V AC
400 gRL 690 V AC
500 gRL 690 V AC
630 gRL 690 V AC
630 gRL 690 V AC
MG80C502
