Danfoss VLT AHF 005 Design Manual page 82

Specifications
X1 Mains 300 mm
7 7
Illustration 7.45 IP20 X7 Internal Fan 1
Illustration 7.46 IP20 X7 Internal Fan 1, 3D View
80
X3/X4 Capacitor disconnect 120 mm
A/B Temperature 2.5 mm
2
X2 Drive 300 mm
F1
F2
PE M12
158.5 ±2.5 mm [6.2 ±0.1 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
Danfoss A/S © 10/2016 All rights reserved.
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
2
2
2
715.0 ±2.5 mm [28.1 ±0.1 in]
300.0 ±1.0 mm [11.8 ±0.04 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
800.0 ±2.5 mm [31.5 ±0.1 in]
948.5 ±4.0 mm [37.3 ±0.6 in]
420.0 ±2.5 mm [16.5 ±0.1 in]
468.0 ±2.5 mm [18.4 ±0.1 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
MG80C502
