Specifications
323.3 ±2.5 mm [12.7 ±0.1 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
Illustration 7.107 X7 IP21 External Fan 2
Illustration 7.108 X7 IP21 External Fan 2, 3D View
MG80C502
Design Guide
1169 ±4.0 mm [46.0 ±0.16 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
300.0 ±1.0 mm [11.8 ±0.04 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
800.0 ±2.5 mm [31.5 ±0.1 in]
1196 ±4.0 mm [47.1 ±0.16 in]
Danfoss A/S © 10/2016 All rights reserved.
420.0 ±2.5 mm [16.5 ±0.1 in]
468.0 ±2.5 mm [18.4 ±0.1 in]
92.8 ±2.5 mm [3.7 ±0.1 in]
111
7
7
