Specifications
205 ±1 mm [8.1 ±0.04 in]
7
7
Illustration 7.65 IP21 X2 Internal Fan 1
Illustration 7.66 IP21 X2 Internal Fan 1, 3D View
90
®
VLT
Advanced Harmonic Filter AHF 005/AHF 010
582 ±2.5 mm [22.9 ±0.1 in]
382 ±2.5 mm [15.0 ±0.1 in]
174 ±2.5 mm [6.8 ±0.1 in]
185 ±2.5 mm [7.3 ±0.1 in]
534 ±2.5 mm [21.0 ±0.10 in]
611 ±2.5 mm [24.0 ±0.1 in]
Danfoss A/S © 10/2016 All rights reserved.
238 ±2 mm [9.4 ±0.08 in]
232 ±2 mm [9.1 ±0.1 in]
58 ±2.5 mm [2.3 ±0.1 in]
MG80C502
