Specifications
242.8 ±2.5 mm [9.6 ±0.1 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
Illustration 7.99 IP21 X6 External Fan 2
Illustration 7.100 IP21 X6 External Fan 2, 3D View
MG80C502
Design Guide
942.0 ±4.0 mm [37.1 ±0.16 in]
210.5 ±1.0 mm [8.3 ±0.04 in]
210.5 ±1.0 mm [8.3 ±0.04 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
685.0 ±2.5 mm [27.0 ±0.1 in]
757.6 ±2.5 mm [29.8 ±0.1 in]
984.6 ± 4.0 mm [38.8 ± 0.16 in]
Danfoss A/S © 10/2016 All rights reserved.
370.0 ±2.5 mm [14.6 ±0.1 in]
418.0 ±2.5 mm [16.5 ±0.1 in]
84.6 ±2.5 mm [3.3 ±0.1 in]
107
7
7
