Digital input function
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset counter B
Mech. brake feedb.
Mech. brake feedb. inv.
PID error inv.
PID reset I-part
PID enable
MCO specific
PTC card 1
PROFIdrive OFF2
6 6
PROFIdrive OFF3
Light-load detection
Mains Loss
Mains loss inverse
Start edge triggered
Safety option reset
Start homing
Activate touch
Relative position
Enable reference
Sync. to position mode
Home sensor
Home sensor inverse
Touch sensor
Touch sensor inverse
Table 6.2 Digital Input Function
®
VLT AutomationDrive FC 301/FC 302 standard terminals
are 18, 19, 27, 29, 32, and 33. Terminal 29 functions as an
output only in FC 302.
Functions dedicated to only 1 digital input are stated in
the associated parameter.
All digital inputs can be programmed to these functions:
[0] No
operation
[1] Reset
[2] Coast
inverse
[3] Coast and
reset
inverse
48
VLT
Select Terminal
[61] 29, 33
[62] All
[63] 29, 33
[64] 29, 33
[65] All
[70] All
[71] All
[72] All
[73] All
[74] All
[75] –
[80] All
[91] –
[92] –
[94] All
[96] 32, 33
[97] 32, 33
[98] –
[100] Resets the safety
option. Available only
when the safety option
is mounted.
[110] All
[111] All
[112] All
[113] All
[114] All
[115] 18, 32, 33
[116] 18, 32, 33
[117] 18, 32, 33
[118] 18, 32, 33
No reaction to signals transmitted to the
terminal.
Resets frequency converter after a trip/alarm.
Not all alarms can be reset.
(Default digital input 27): Coast stop, inverted
input (NC). The frequency converter leaves the
motor in free mode. Logic 0⇒coast stop.
Reset and coast stop inverted input (NC).
Leaves motor in free mode and resets
frequency converter. Logic 0⇒coast stop and
reset.
Danfoss A/S © 10/2016 All rights reserved.
®
Advanced Harmonic Filter AHF 005/AHF 010
[4] Quick stop
inverse
[5] DC brake
inverse
[6] Stop
inverse
[8] Start
[9] Latched
start
[10] Reversing
[11] Start
reversing
[12] Enable
start
forward
Inverted input (NC). Generates a stop in
accordance with quick stop ramp time set in
parameter 3-81 Quick Stop Ramp Time. When
the motor stops, the shaft is in free mode.
Logic 0⇒quick stop.
Inverted input for DC brake (NC). Stops motor
by energizing it with a DC current for a certain
time period. See parameter 2-01 DC Brake
Current to parameter 2-03 DC Brake Cut In Speed
[RPM]. The function is only active when the
value in parameter 2-02 DC Braking Time is
different from 0. Logic 0⇒DC brake.
Stop inverted function. Generates a stop
function when the selected terminal goes from
logical level 1 to logical level 0.
The stop is performed according to the
selected ramp time:
•
Parameter 3-42 Ramp 1 Ramp Down
Time,
•
Parameter 3-52 Ramp 2 Ramp Down
Time,
•
Parameter 3-62 Ramp 3 Ramp down
Time, and
•
Parameter 3-72 Ramp 4 Ramp Down
Time.
NOTICE
When the frequency converter is at the
torque limit and has received a stop
command, it may not stop by itself. To
ensure that the frequency converter
stops, configure a digital output to [27]
Torque limit and stop. Connect this digital
output to a digital input that is
configured as coast.
(Default digital input 18): Select start for a
start/stop command. Logic 1 = start,
logic 0 = stop.
If a pulse is applied for minimum 2 ms, the
motor starts. The motor stops when stop
inverse is activated, or a reset command (via
DI) is given.
(Default digital input 19). Change the direction
of motor shaft rotation. Select logic 1 to
reverse. The reversing signal only changes the
direction of rotation. It does not activate the
start function. Select both directions in
parameter 4-10 Motor Speed Direction. The
function is not active in process closed loop.
Used for start/stop and for reversing on the
same wire. Signals on start are not allowed at
the same time.
Disengages the counterclockwise movement
and allows clockwise direction.
MG80C502
