Specifications
243 ±2.5 mm [9.6 ±0.1 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
Illustration 7.95 IP21 X6 Internal Fan 2
Illustration 7.96 IP21 X6 Internal Fan 2, 3D View
MG80C502
Design Guide
922.0 ±4.0 mm [36.3 ±0.16 in]
210.5 ±1.0 mm [8.3 ±0.04 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
685.0 ±2.5 mm [27.0 ±0.1 in]
737.6 ±2.5 mm [29.0 ±0.1 in]
964.6 ±4.0 mm [38.0 ±0.16 in]
Danfoss A/S © 10/2016 All rights reserved.
370.0 ±2.5 mm [14.6 ±0.1 in]
418.0 ±2.5 mm [16.5 ±0.1 in]
210.5 ±1.0 mm [8.3 ±0.04 in]
64.6 ±2.5 mm [2.5 ±0.1 in]
7
7
105
